Mares Abyss 52 regulator

Abyss is available with the compact top performer MR52 first stage:the best for a unique high calibre set up. Double DFC system provides a consistent flow of air at any depth, even when breathing simultaneously from both the primary second stage and the octopus. The NCC system and the design of the Abyss second stage with more metal on the front cover, allows this combination to achieve very high performance in cold water. Pre-oriented pressure ports for an ideal placement of hoses even using two independent regulators.

Material: Metal
First stage: Balanced diaphragm design
First stage weight (g) INT: 687
First stage weight (g) DIN300: 513
Second stage weight (g): 269
Total weight (g) INT: 1106
Total weight (g) DIN300: 929
Oil/Dry cold water kit: Oil
Nitrox: -
HP Ports: 2 HP 7/16" UNF ports
LP Ports: 4Lp 3/8" UNF ports
Inhale pressure: 7.83 mbar
Inhale pos pressure: 2.18 mbar
Exhale pressure: 8.23 mbar
Ext work breathing: 0.88 J/l
Inhale work: 0.27 J/l
Pos inhale work: 0.00 J/l
Exhale work: 0.61 J/l
Pressure depth: 50m (165ft)
